Home / Products / Electromechanically assisted opening system JC35TMQ

JC35TMQ is an electric door pusher for embedded refrigerator doors, tall cabinets and floor cabinets. Features include:

1. Small installation size for easy replacement

2. Low noise, large load

3. High stability, easy installation, flexible placement

4. Built-in magnetic linear Hall sensor, high sensitivity

QUICK LINKS

COMPONENTS

SYSTEMS

Add: No.2 Laisheng Road, Provincial High-tech industrial park, Xinchang county, Zhejiang province, China

Tel: 400-6666-358
Wechat: +86 18057561965
WhatsApp: +86 18057561965

Voltage	24VDC
Max. load	100N
No-load speed	35mm/s
Load speed	35mm/s
Self-locking force	＞9kg
Stroke	40mm
Installation height	22mm
Color	Black
Duty cycle	40%, max. 8min.continuous working and 12min.off
Static bending moment	No side loads allowed
Ambient temperature	-10～+45℃
Noise level	＜55dB
IP grade	IP43
Installation method	Motor installed horizontally
Limiting method	Hall sensor
Overload protection	Current protection

Voltage	24VDC
Max. load	100N
No-load speed	35mm/s
Load speed	35mm/s
Self-locking force	＞9kg
Stroke	40mm
Installation height	22mm
Color	Black
Duty cycle	40%, max. 8min.continuous working and 12min.off
Static bending moment	No side loads allowed
Ambient temperature	-10～+45℃
Noise level	＜55dB
IP grade	IP43
Installation method	Motor installed horizontally
Limiting method	Hall sensor
Overload protection	Current protection
