Lifting Column JS36DC1-2-S
JIECANG
JS36DC1-2-S is a round shape 2 stage no hole column, perfect for a wide range of different desk applications. The column is very clean and compact in design, which also is a cost effective alternative to model: JS36DC1-3-S.
JS36DC1-2-S has the same outer dimensions and mounting holes as JS36DC1-3-S, which makes the compatible and they can be used in the same frame & foot construction.
JS36DC1-2-S is available in several standard colours to fit into a wide range of desk designs.
The function of anti-collision minimize the risk of damages when desk collision with an obstacle.
JS36DC1-2-S is compatible with all the standard Jiecang control boxes, and ensures a very low and pleasant noise level, and steady movement.
Furthermore, the system has a very low standby power consumption less than 0.1W.
JS36DC1-2-S is a round shape 2 stage no hole column, perfect for a wide range of different desk applications. The column is very clean and compact in design, which also is a cost effective alternative to model: JS36DC1-3-S.
JS36DC1-2-S has the same outer dimensions and mounting holes as JS36DC1-3-S, which makes the compatible and they can be used in the same frame & foot construction.
JS36DC1-2-S is available in several standard colours to fit into a wide range of desk designs.
The function of anti-collision minimize the risk of damages when desk collision with an obstacle.
JS36DC1-2-S is compatible with all the standard Jiecang control boxes, and ensures a very low and pleasant noise level, and steady movement.
Furthermore, the system has a very low standby power consumption less than 0.1W.
Type | Rated load (N) | Self locking (N) | Typical current at rated load (A) | Typical Max speed 0 load ~ Rated load (mm/s) | Duty cycle | Stroke length (mm) | Built-in length (mm) |
JS36DC1-2-S | 800 | 1200 | 5 | 32 | 10% | 500 | 650 |
Type | Rated load (N) | Self locking (N) | Typical current at rated load (A) | Typical Max speed 0 load ~ Rated load (mm/s) | Duty cycle | Stroke length (mm) | Built-in length (mm) |
JS36DC1-2-S | 800 | 1200 | 5 | 32 | 10% | 500 | 650 |
